Manufacturing Capabilities

Electronics Manufacturing Capabilities

US-based contract electronics manufacturing from prototype to high-volume production — in-house SMT, inspection, test, conformal coating, and box build at our AS9100D-certified, 45,000 sq. ft. facility in Norcross, GA.

SMT Assembly

Pick-and-Place

MYDATA / Mycronic MY100SX (SMT1)

  • •Throughput: 21,500 CPH rated, ~17,800 CPH IPC-9850
  • •Component range: 01005–QFP/flip-chip
  • •Typical max part: ~18.6×18.6×5.6 mm

Use Case: Dual Vision, high-precision head, on-the-fly electrical verification

JUKI KE-3020 class (SMT2)

  • •Placement accuracy: ±0.05 mm (laser); ±0.03–0.04 mm (vision/MNVC)
  • •Component sizes: 01005 to ~33.5 mm
  • •Tall parts up to 25 mm (XL)

Use Case: Dual-lane configuration available for higher UPH

MYDATA MY12E (SMT3)

  • •Dual-mode: 21,000 CPH (HYDRA) for chips
  • •~6,100 CPH for fine-pitch
  • •Handles QFP, CSP, BGA

Use Case: Ideal for flexible short-run/high-mix work

Printing & SPI

Solder Paste Application

DEK Horizon 03iX / ASM-DEK (SMT1 & SMT3)

  • •Board size: 40×50 mm up to 508×508 mm
  • •Thickness: 0.2–6 mm
  • •Alignment capability: ≈±25 µm @ 2.0 Cmk

Use Case: 2D paste inspection available

JUKI PMAXII (Large-format printer – SMT2)

  • •Stencil range up to 1500×1250 mm
  • •Dual independent heads
  • •Programmable squeegee: 0–30 kg, 5–150 mm/s

Use Case: Closed-loop with SPI

AMS / VI Technology 3D SPI

  • •Modern 3D SPI detects height/volume/area/alignment
  • •Prevents >70% of print-related defects
  • •Supports 0201 (metric) pads

Use Case: Real-time analytics, line-integrated

Reflow

Solder Reflow Systems

ERSA HOTFLOW 3/20 (SMT1)

  • •10 heating zones (7 preheat + 3 peak)
  • •Multi-level cooling, dual-track options
  • •Conveyor speed 20–200 cm/min

Use Case: Process length >5 m; robust nitrogen & energy management

HELLER 1809 (MK series) (SMT3)

  • •9 heated zones with low ΔT
  • •Energy management
  • •Medium/high-volume capable

Use Case: Proven reliability for consistent thermal profiles

JUKI RS-800II (SMT2)

  • •8 heat / 2 cool zones
  • •3.12 m heated length, 300 °C zone capability
  • •<±2 °C ΔT; nitrogen-ready

Use Case: Precise temperature control for sensitive components

Selective/Wave

Through-Hole Soldering

ACE KISS-103 Selective Solder

  • •Traveling mini-wave system for tight-clearance THT
  • •Board size up to 18″×24″
  • •~30 lb pot; automated fluxing

Use Case: Precise molten delivery on dense SMT boards

ERSA / JUKI CUBE.460 Selective Solder

  • •PCB size up to 460×460 mm
  • •0°/7° tilt, program-controlled solder temp/height
  • •Multiple mini-wave nozzles (Ø4–20 mm)

Use Case: Nitrogen capable; ideal for complex assemblies

DDM Novastar Wave Solder

  • •Lead/lead-free, single or dual wave
  • •Wave widths 14–24″ with quick-change pots
  • •Conveyor 0.5–2.5 m/min

Use Case: Model-dependent configuration for various throughput needs

Inspection & Test

Quality Verification

Parmi Xceed New Generation 3D AOI

  • •4 Mega Pixel Telecentric Lens Fast Speed CMOS camera
  • •Fastest Inspection Speed: 65cm² @ 14×14µm resolution
  • •Guarantee accuracy up to 10mm (±5mm) warpage

Use Case: Ultra-fast 3D inspection with high warpage tolerance

Glenbrook JewelBox

  • •80 kV / 100 µA source
  • •Variable 7×–2000× magnification
  • •~10 µm focal spot

Use Case: Ideal for BGA/QFN voiding & barrel-fill analysis

SPEA Flying-Probe Test

  • •Ultra-high-speed 4-probe platform
  • •Linear encoders down to 12 nm resolution
  • •Supports opens/shorts, analog, boundary-scan

Use Case: Comprehensive electrical testing without custom fixtures

Cleaning & Coating

Protection Systems

Aqueous Technologies TRIDENT DUO Batch Cleaner

  • •Closed-loop / low-discharge aqueous deflux
  • •SPC tracking with dual-chamber configurations
  • •Recipe control and barcode logging

Use Case: Thorough cleaning with environmental efficiency

SCS PrecisionCoat V Conformal Coating

  • •Automated selective coating/dispense platform
  • •Supports solvent, water-based, and 100% solids materials
  • •Multi-head, high-accuracy motion control

Use Case: Precision coating for environmental protection

Rework

BGA/QFN/CSP/PoP

Air-Vac Engineering DRS-25 / DRS-27

  • •Semi-auto & high-mass rework systems
  • •Closed-loop mass-flow heat control, 8 thermocouples
  • •Large board support up to ~32″×24″ (DRS-27)

Use Case: Proven capability down to 01005, precise vision alignment, programmable board cooling

Inline PCB Cleaner & Nitrogen Generation

  • •Inline high-pressure PCB cleaning
  • •On-site nitrogen supply
  • •Low residual O₂ support

Use Case: Stable reflow/selective soldering with improved wetting and reduced defects

Manufacturing Capabilities FAQ

Common questions about production volumes, US-based manufacturing, lead times, and certifications.

We support the full range — from prototype and low-volume builds through medium- and high-volume production. Prototype assembly ships in 5-7 days (3-day express available), and our two SMT lines (MYDATA and JUKI) scale into repeatable medium/high-volume production runs on the same floor.
